Beskrivning
- Extra slim 1/4″ plug
- Robust die-cast shell in stylish design
- Proven chuck type strain relief for reliable cable retention
- Sleek design for best handling convenience
- Precision machined one-piece contacts – avoid hook up of tip contact
3-pin 1/4″ professional phone plug, nickel contacts, nickel shell
The heavy duty professional phone plug series improves on the design of the existing C series by offering the thinnest available A-gauge 1/4″ plug with unique Neutrik chuck type strain relief on the market. The slimline shell with a width of 14.5 mm meets the most recent requirements for highest density jackfields (15.88 mm jack pitch).
The precise machined one-piece tip contact without rivets makes it unique and avoids hook up in a socket or break off the tip.
The Plug X Series serves all applications such as guitar applications, audio cables, snakes, speakers, amplifiers and mixing desks.
Specifications
Flashover Voltage: 1000 V
Impedance: 100000 Ω
Brand Connector 1: Neutrik
Pins: 3
Wire Connection: 1 mm²
Maximum Wire Size: 1 mm²
Maximum Wire Size AWG: 18 AWG
Outer Cable Diameter: 7 mm
Length (mm): 93 mm
Height (mm): 15 mm
Width (mm): 15 mm
Diameter: 15 mm
Weight: 0.026 kg
Housing: Metal
Colour: Silver
Bushing Colour: Black
Contact Resistance: 6 < mΩ
Pin Connection: Solder
Contact Type: Nickel plated
Maximum Ambient Temperature: 65 °C
Minimum Ambient Temperature: -20 °C
